5.2 Setting Basic Settings of Measurement

136

4

Press to close the setting screen.

3

Sweep Parameter Setting

Select the sweep parameter.

Performs frequency sweep.

Performs open circuit voltage sweep.

Performs constant voltage sweep.

Performs constant current sweep.
