4
Press to close the setting screen.
3
Trigger Setting
Select the trigger setting.
Performs a sequential sweep.
When an external trigger is input, sweep
measurement is performed once only.
Performs a repeat sweep.
An internal trigger results in a sweep being
performed repeatedly.
Performs a step sweep.
When an external trigger is input, measure-
ment is performed at the current measure-
ment point and then the process moves to
the next measurement point.
• If this is set to or , is
displayed in the measurement screen.
• Each time you press , a sequence
sweep or step sweep is performed.
The trigger setting that is set for this item differs from the trigger setting of LCR mode.
(It does not influence the trigger setting of LCR mode.)
