5.9 Application Settings
223
5
Chapter 5 ANALYZER Function
3
HIGH-Z Setting
Select ON/ OFF for the HIGH-Z reject function.
Sets the HIGH-Z reject function to OFF.
Sets the HIGH-Z reject function to ON.
5
4
Press to close the setting screen.
HIGH-Z Setting
Use or to set the judgment reference
value.
Settable range: 0% to 30000%
• A ratio is set using the range name as the reference
value.
Example: When using the 1 k range, a ratio to the
value of 1 k is set.
• If you make a mistake during input:
press to cancel the input and start again.
