4
Setting the method of analysis
5
Press to close the setting screen.
Selects the method of analysis.
Performs analysis when is pressed.
Performs analysis automatically after measure-
ment completes.
• is valid only when the trigger is set to "Sequential sweep" or "Step sweep."
Analysis will not be performed automatically when the trigger is set to "Repeat sweep."
• Equivalent circuit analysis cannot be performed manually on the Continuous Measurement
screen. To perform equivalent circuit analysis during continuous measurement, change the setting
to auto and save the panel.
See "5.2.3 Setting the Trigger" (p. 137)
To Next Page
