5.10 Equivalent Circuit Analysis Function
249
5
Chapter 5 ANALYZER Function
6
Press and set the coefficient with the
numeric keypad.
Coefficient Settings
Set a different coefficient relative to Poisson's
ratio only when selecting (planar
oscillation) as the oscillation mode.
Press to accept the coefficient.
Settable range: 0.000001 to 1.000000
To return to the previous screen without making any
change to the set value, press the key when the
screen is in the state with nothing being displayed (the
state after pressing the key).
7
Press to set the same coefficient as .
8
Press to close the setting screen.
