5.10 Equivalent Circuit Analysis Function
251
5
Chapter 5 ANALYZER Function
4
Setting the analysis result display position
5
Press to close the setting screen.
Select the position at which to display analysis
results.
Displays estimate results on the left.
Displays estimate results on the right.
Displays estimate results on the top.
Displays estimate results on the bottom.
Analysis result display position
Analysis result
When set to UPPER
When set to LEFT
When set to RIGHT
When set to LOWER
