7.2 Short Circuit Compensation
284
Acquiring short compensation values for some frequencies only
Press to start acquiring
compensation values.
1
2
3
All Compensation
Setting the compensation range
All Compensation
Press in the all compensation
screen.
Configuring DC short compensation
Configuring AC short compensation
Press and set the start frequency
for short compensation with the numeric
keypad.
Press and set the stop frequency
for short compensation with the numeric
keypad.
Press to accept the settings.
Initial value (perform compensation for all fre-
quencies):
Press .
Procedure
Performs DC short compensation.
Does not perform DC short compensation.
The DC on/off setting and AC start/stop setting apply to both open compensation and short
compensation.
