11.1 External Input/Output Connector and Signals
368
PARA1-HI, PARA1-LO,
PARA1-IN
LCR mode: Outputs the comparator judgment result for the measurement values of the first
parameter.
Analyzer mode: Outputs the analyzer comparator result of the first parameter in AREA mode.
PARA3-HI, PARA3-LO,
PARA3-IN
LCR mode: Outputs the comparator judgment result for the measurement values of the third
parameter.
Analyzer mode: Outputs the analyzer comparator result of the third parameter in AREA
mode.
PARA1_LMAX_MEASNG
,
PARA1_LMAX_CONDN
G, PARA1_LMAX_IN
Analyzer mode: Outputs the analyzer comparator result for the local maximum value of the
first parameter in PEAK mode.
(Outputs PARA1_LMAX_MEASNG if the vertical axis (measurement value) is out of the
range or there is no comparison peak, outputs PARA1_LMAX_CONDNG if the horizontal
axis (sweep setting) is out of the range or there is no comparison peak, and outputs
PARA1_LMAX_IN if the PEAK is IN.)
PARA2_LMAX_MEASNG
,
PARA2_LMAX_CONDN
G, PARA2_LMAX_IN
Analyzer mode: Outputs the analyzer comparator result for the local maximum value of the
second parameter in PEAK mode.
(Outputs PARA2_LMAX_MEASNG if the vertical axis (measurement value) is out of the
range or there is no comparison peak, outputs PARA2_LMAX_CONDNG if the horizontal
axis (sweep setting) is out of the range or there is no comparison peak, and outputs
PARA2_LMAX_IN if the PEAK is IN.)
PARA1_LMIN_MEASNG,
PARA1_LMIN_CONDNG,
PARA1_LMIN_IN
Analyzer mode: Outputs the analyzer comparator result for the local minimum value of the
first parameter in PEAK mode.
(Outputs PARA1_LMIN_MEASNG if the vertical axis (measurement value) is out of the range
or there is no comparison peak, outputs PARA1_LMIN_CONDNG if the horizontal axis
(sweep setting) is out of the range or there is no comparison peak, and outputs
PARA1_LMIN_IN if the PEAK is IN.)
PARA2_LMIN_MEASNG,
PARA2_LMIN_CONDNG
,
PARA2_LMIN_IN
Analyzer mode: Outputs the analyzer comparator result for the local minimum value of the
first parameter in PEAK mode.
(Outputs PARA2_LMIN_MEASNG if the vertical axis (measurement value) is out of the range
or there is no comparison peak, outputs PARA2_LMIN_CONDNG if the horizontal axis
(sweep setting) is out of the range or there is no comparison peak, and outputs
PARA2_LMIN_IN if the PEAK is IN.)
AND
Outputs the result that takes the AND of the judgment results of the measurement values of
the two parameters judged in both LCR mode and analyzer mode.
The result is output when both judgment results are IN or if either one of the first and third
parameters is not judged and the judgment result of the judged parameter is IN.
BIN1 to BIN10
OUT OF BINS
Outputs the judgment result of BIN measurement.
CIRCUIT_NG Outputs the equivalent circuit analysis comparator judgment results.
INDEX
This is the signal to indicate that A/D conversion in the measurement circuit has ended.
When this signal changes from HIGH (OFF) to LOW (ON), the test sample can be changed.
EOM
This is the end of measurement signal.
At this point in time, the comparator judgment result is confirmed.
ERR
Outputs when there is a sampling error, constant voltage/current error, voltage/current limit
value exceeded error, contact check error in low Z high accuracy mode, HIGH-Z reject error
or monitoring the detection level.
