13.3 About Measurement Times and Measurement Speed
400
Measurement times= INDEX + A + B + C + D + E + F
Measurement times (EOM)
A. Calculation time (no OPEN /SHORT/ LOAD compensation, HOLD range, normal measurement)
FAST MED SLOW SLOW2
All frequencies 0.5 ms
Tolerance: ±10% ±0.1 ms
B. OPEN/ SHORT/ LOAD compensation
OPEN/ SHORT/ LOAD
compensation
No 0.0 ms
Yes MAX 0.4 ms
C. Measurement mode
Measurement mode
Normal measurement 0.0 ms
Comparator measurement
MAX 0.4 ms
BIN measurement MAX 0.8 ms
D. Screen Display
Screen display
When no screen display 0.0 ms
When screen display MAX 0.3 ms
E. Saving to memory
Saving to memory
Memory function ON/ IN MAX 0.4 ms
Memory function OFF 0.0 ms
F. Equivalent circuit analysis (optional IM9000)
Equivalent circuit analysis*
Analysis OFF
0.0 ms
Equivalent circuit model: A to D
MAX 2.5 ms
Equivalent circuit model: E MAX 3.5 ms
* Using 201 sweep points, equivalent circuit model selection
hold, and auto analysis.
