4.3 Setting DC Resistance Measurement

81

4

Chapter 4 LCR Function

4

Press to close the setting screen.

When you want to cancel the averaging

function: Press .

The number of averaging times is set to 1.

3

No. of Averaging Times Setting

Use or to enter the number of aver-

aging times.

Settable range: 1 to 256
