Datasheet 743
SMBus Controller Registers (D31:F3)
18.1.10 SMBMBAR1—D31_F3_SMBus Memory Base Address 1
(SMBus—D31:F3)
Address Offset: 14h–17h Attributes: R/W
Default Value: 00000000h Size: 32 bits
18.1.11 SMB_BASE—SMBus Base Address Register
(SMBus—D31:F3)
Address Offset: 20–23h Attribute: R/W, RO
Default Value: 00000001h Size: 32-bits
18.1.12 SVID—Subsystem Vendor Identification Register
(SMBus—D31:F2/F4)
Address Offset: 2Ch–2Dh Attribute: RO
Default Value: 0000h Size: 16 bits
Lockable: No Power Well: Core
Bit Description
31:0
Base Address — R/W. Provides bits 63:32 system memory base address for the PCH
SMB logic.
Bit Description
31:16 Reserved — RO
15:5
Base Address — R/W. This field provides the 32-byte system I/O base address for the
PCH’s SMB logic.
4:1 Reserved — RO
0 IO Space Indicator — RO. Hardwired to 1 indicating that the SMB logic is I/O mapped.
Bit Description
15:0
Subsystem Vendor ID (SVID) — RO. The SVID register, in combination with the
Subsystem ID (SID) register, enables the operating system (OS) to distinguish
subsystems from each other. The value returned by reads to this register is the same as
that which was written by BIOS into the IDE SVID register.
NOTE: Software can write to this register only once per core well reset. Writes should
be done as a single 16-bit cycle.
