Datasheet 857
Thermal Sensor Registers (D31:F6)
22.2.7 TSES—Thermal Sensor Error Status
Offset Address: TBARB+0Ch Attribute: R/WC
Default Value: 00h Size: 8 bit
Bit Description
7
Auxiliary2 High-to-LowEvent — R/WC.
0 = No trip occurs.
1 = Indicates that an Auxiliary2 Thermal Sensor trip event occurred based on a higher
to lower temperature transition through the trip point.
Software must write a 1 to clear this status bit.
6
Catastrophic High-to-LowEvent — R/WC.
0 = No trip occurs.
1 = Indicates that a Catastrophic Thermal Sensor trip event occurred based on a
higher to lower temperature transition through the trip point.
1 = Software must write a 1 to clear this status bit.
5
Hot High-to-LowEvent — R/WC.
0 = No trip occurs.
1 = Indicates that a Hot Thermal Sensor trip event occurred based on a higher to
lower temperature transition through the trip point.
Software must write a 1 to clear this status bit.
4
Auxiliary High-to-LowEvent — R/WC.
0 = No trip occurs.
1 = Indicates that an Auxiliary Thermal Sensor trip event occurred based on a higher
to lower temperature transition through the trip point.
Software must write a 1 to clear this status bit.
3
Auxiliary2 Low-to-High Event — R/WC.
0 = No trip occurs.
1 = Indicates that an Auxiliary2 Thermal Sensor trip event occurred based on a lower
to higher temperature transition through the trip point.
Software must write a 1 to clear this status bit.
2
Catastrophic Low-to-High Event — R/WC.
0 = No trip occurs.
1 = Indicates that a Catastrophic Thermal Sensor trip event occurred based on a lower
to higher temperature transition through the trip point.
Software must write a 1 to clear this status bit.
1
Hot Low-to-High Event — R/WC.
0 = No trip occurs.
1 = Indicates that a hot Thermal Sensor trip event occurred based on a lower to
higher temperature transition through the trip point.
Software must write a 1 to clear this status bit.
0
Auxiliary Low-to-High Event — R/WC.
0 = No trip occurs.
1 = Indicates that an Auxiliary Thermal Sensor trip event occurred based on a lower to
higher temperature transition through the trip point.
Software must write a 1 to clear this status bit.
