Intel® Management Engine Interface (MEI) Subsystem Registers (D22:F0)
882 Datasheet
23.2.8 MEI_MBAR—MEI MMIO Base Address Register
(MEI—D22:F1)
Address Offset: 10h–17h Attribute: R/W, RO
Default Value: 0000000000000004h Size: 64 bits
This register allocates space for the Intel MEI memory mapped registers.
23.2.9 SVID—Subsystem Vendor ID Register
(MEI—D22:F1)
Address Offset: 2Ch–2Dh Attribute: R/WO
Default Value: 0000h Size: 16 bits
23.2.10 SID—Subsystem ID Register
(MEI—D22:F1)
Address Offset: 2Eh–2Fh Attribute: R/WO
Default Value: 0000h Size: 16 bits
Bit Description
63:4
Base Address (BA) — R/W. Software programs this field with the base address of
this region.
3 Prefetchable Memory (PM) — RO. Indicates that this range is not pre-fetchable.
2:1
Type (TP) — RO. Set to 10b to indicate that this range can be mapped anywhere in
64-bit address space.
0
Resource Type Indicator (RTE) — RO. Indicates a request for register memory
space.
Bit Description
15:0
Subsystem Vendor ID (SSVID) — R/WO. Indicates the sub-system vendor
identifier. This field should be programmed by BIOS during boot-up. Once written, this
register becomes Read Only. This field can only be cleared by PLTRST#.
NOTE: Register must be written as a Word write or as a DWord write with SID register.
Bit Description
15:0
Subsystem ID (SSID) — R/WO. Indicates the sub-system identifier. This field should
be programmed by BIOS during boot-up. Once written, this register becomes Read
Only. This field can only be cleared by PLTRST#.
NOTE: Register must be written as a Word write or as a DWord write with SVID
register.
