Keysight Technologies InfiniiVision MSO-X 4154A

144 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 28 :SBUS<n>:CAN Commands Summary
Command Query Options and Query Returns
n/a :SBUS<n>:CAN:COUNt:ER
Ror? (see page 780)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:CAN:COUNt:OV
ERload? (see page 781)
<frame_count> ::= 0 in NR1 format
:SBUS<n>:CAN:COUNt:RE
Set (see page 782)
n/a n/a
n/a :SBUS<n>:CAN:COUNt:SP
EC? (see page 783)
<spec_error_count> ::= integer
in NR1 format
n/a :SBUS<n>:CAN:COUNt:TO
Tal? (see page 784)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:CAN:COUNt:UT
ILization? (see
page 785)
<percent> ::= floating-point in
NR3 format
:SBUS<n>:CAN:DISPlay
<type> (see page 786)
:SBUS<n>:CAN:DISPlay?
(see page 786)
<type> ::= {HEXadecimal |
SYMBolic}
:SBUS<n>:CAN:FDSPoint
<value> (see page 787)
:SBUS<n>:CAN:FDSPoint
? (see page 787)
<value> ::= even numbered
percentages from 30 to 90 in NR3
format.
:SBUS<n>:CAN:FDSTanda
rd <std> (see
page 788)
:SBUS<n>:CAN:FDSTanda
rd? (see page 788)
<std> ::= {ISO | NISO}
:SBUS<n>:CAN:SAMPlepo
int <percent> (see
page 789)
:SBUS<n>:CAN:SAMPlepo
int? (see page 789)
<percent> ::= 30.0 to 90.0 in NR3
format
:SBUS<n>:CAN:SIGNal:B
AUDrate <baudrate>
(see page 790)
:SBUS<n>:CAN:SIGNal:B
AUDrate? (see
page 790)
<baudrate> ::= integer from 10000
to 4000000 in 100 b/s increments,
or 5000000
:SBUS<n>:CAN:SIGNal:D
EFinition <value>
(see page 791)
:SBUS<n>:CAN:SIGNal:D
EFinition? (see
page 791)
<value> ::= {CANH | CANL | RX |
TX | DIFFerential | DIFL | DIFH}
:SBUS<n>:CAN:SIGNal:F
DBaudrate <baudrate>
(see page 792)
:SBUS<n>:CAN:SIGNal:F
DBaudrate? (see
page 792)
<baudrate> ::= integer from 10000
to 10000000 in 100 b/s
increments.
