Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 145
:SBUS<n>:CAN:SOURce
<source> (see
page 793)
:SBUS<n>:CAN:SOURce?
(see page 793)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> |} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:CAN:TRIGger
<condition> (see
page 794)
:SBUS<n>:CAN:TRIGger?
(see page 795)
<condition> ::= {SOF | EOF |
IDData | DATA | FDData | IDRemote
| IDEither | ERRor | ACKerror |
FORMerror | STUFferror | CRCerror
| SPECerror | ALLerrors | BRSBit
| CRCDbit | EBActive | EBPassive
| OVERload | MESSage | MSIGnal |
FDMSignal}
:SBUS<n>:CAN:TRIGger:
IDFilter {{0 | OFF} |
{1 | ON}} (see
page 797)
:SBUS<n>:CAN:TRIGger:
IDFilter? (see
page 797)
{0 | 1}
:SBUS<n>:CAN:TRIGger:
PATTern:DATA <string>
(see page 798)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA? (see
page 798)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:DLC
<dlc> (see page 799)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:DLC?
(see page 799)
<dlc> ::= integer between -1
(don't care) and 64, in NR1
format.
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 800)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:LENGth?
(see page 800)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:STARt
<start> (see page 801)
:SBUS<n>:CAN:TRIGger:
PATTern:DATA:STARt?
(see page 801)
<start> ::= integer between 0 and
63, in NR1 format.
:SBUS<n>:CAN:TRIGger:
PATTern:ID <string>
(see page 802)
:SBUS<n>:CAN:TRIGger:
PATTern:ID? (see
page 802)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE
<value> (see page 803)
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE? (see
page 803)
<value> ::= {STANdard | EXTended}
Table 28 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
