Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 149
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID
<frame_id> (see
page 841)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:ID? (see
page 841)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE
<frame_type> (see
page 842)
:SBUS<n>:FLEXray:TRIG
ger:FRAMe:TYPE? (see
page 842)
<frame_type> ::= {NORMal |
STARtup | NULL | SYNC | NSTArtup
| NNULl | NSYNc | ALL}
Table 30 :SBUS<n>:FLEXray Commands Summary (continued)
Command Query Options and Query Returns
Table 31 :SBUS<n>:I2S Commands Summary
Command Query Options and Query Returns
:SBUS<n>:I2S:ALIGnmen
t <setting> (see
page 845)
:SBUS<n>:I2S:ALIGnmen
t? (see page 845)
<setting> ::= {I2S | LJ | RJ}
:SBUS<n>:I2S:BASE
<base> (see page 846)
:SBUS<n>:I2S:BASE?
(see page 846)
<base> ::= {DECimal | HEX}
:SBUS<n>:I2S:CLOCk:SL
OPe <slope> (see
page 847)
:SBUS<n>:I2S:CLOCk:SL
OPe? (see page 847)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:I2S:RWIDth
<receiver> (see
page 848)
:SBUS<n>:I2S:RWIDth?
(see page 848)
<receiver> ::= 4-32 in NR1 format
:SBUS<n>:I2S:SOURce:C
LOCk <source> (see
page 849)
:SBUS<n>:I2S:SOURce:C
LOCk? (see page 849)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:D
ATA <source> (see
page 850)
:SBUS<n>:I2S:SOURce:D
ATA? (see page 850)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
