150 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:I2S:SOURce:W
SELect <source> (see
page 851)
:SBUS<n>:I2S:SOURce:W
SELect? (see page 851)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:TRIGger
<operator> (see
page 852)
:SBUS<n>:I2S:TRIGger?
(see page 852)
<operator> ::= {EQUal | NOTequal
| LESSthan | GREaterthan |
INRange | OUTRange | INCReasing |
DECReasing}
:SBUS<n>:I2S:TRIGger:
AUDio <audio_ch> (see
page 854)
:SBUS<n>:I2S:TRIGger:
AUDio? (see page 854)
<audio_ch> ::= {RIGHt | LEFT |
EITHer}
:SBUS<n>:I2S:TRIGger:
PATTern:DATA <string>
(see page 855)
:SBUS<n>:I2S:TRIGger:
PATTern:DATA? (see
page 856)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat <base>
(see page 857)
:SBUS<n>:I2S:TRIGger:
PATTern:FORMat? (see
page 857)
<base> ::= {BINary | HEX |
DECimal}
:SBUS<n>:I2S:TRIGger:
RANGe <lower>,<upper>
(see page 858)
:SBUS<n>:I2S:TRIGger:
RANGe? (see page 858)
<lower> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<upper> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
Table 31 :SBUS<n>:I2S Commands Summary (continued)
Command Query Options and Query Returns
