Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 151
:SBUS<n>:I2S:TWIDth
<word_size> (see
page 860)
:SBUS<n>:I2S:TWIDth?
(see page 860)
<word_size> ::= 4-32 in NR1
format
:SBUS<n>:I2S:WSLow
<low_def> (see
page 861)
:SBUS<n>:I2S:WSLow?
(see page 861)
<low_def> ::= {LEFT | RIGHt}
Table 31 :SBUS<n>:I2S Commands Summary (continued)
Command Query Options and Query Returns
Table 32 :SBUS<n>:IIC Commands Summary
Command Query Options and Query Returns
:SBUS<n>:IIC:ASIZe
<size> (see page 863)
:SBUS<n>:IIC:ASIZe?
(see page 863)
<size> ::= {BIT7 | BIT8}
:SBUS<n>:IIC[:SOURce]
:CLOCk <source> (see
page 864)
:SBUS<n>:IIC[:SOURce]
:CLOCk? (see page 864)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC[:SOURce]
:DATA <source> (see
page 865)
:SBUS<n>:IIC[:SOURce]
:DATA? (see page 865)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess
<value> (see page 866)
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess? (see
page 866)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATA <value>
(see page 867)
:SBUS<n>:IIC:TRIGger:
PATTern:DATA? (see
page 867)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2 <value>
(see page 868)
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2? (see
page 868)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
