Keysight Technologies InfiniiVision MSO-X 4154A

174 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SYSTem:RLOGger:TRANs
parent {{0 | OFF} |
{1 | ON}} (see
page 1118)
:SYSTem:RLOGger:TRANs
parent? (see
page 1118)
<setting> ::= {0 | 1}
:SYSTem:RLOGger:WMODe
<write_mode> (see
page 1119)
:SYSTem:RLOGger:WMODe
? (see page 1119)
<write_mode> ::= {CREate |
APPend}
:SYSTem:SETup
<setup_data> (see
page 1120)
:SYSTem:SETup? (see
page 1120)
<setup_data> ::= data in IEEE
488.2 # format.
:SYSTem:TIME <time>
(see page 1122)
:SYSTem:TIME? (see
page 1122)
<time> ::= hours,minutes,seconds
in NR1 format
:SYSTem:TOUCh {{1 |
ON} | {0 | OFF}} (see
page 1123)
:SYSTem:TOUCh? (see
page 1123)
{1 | 0}
Table 56 :SYSTem Commands Summary (continued)
Command Query Options and Query Returns
Table 57 :TIMebase Commands Summary
Command Query Options and Query Returns
:TIMebase:MODE
<value> (see
page 1127)
:TIMebase:MODE? (see
page 1127)
<value> ::= {MAIN | WINDow | XY |
ROLL}
:TIMebase:POSition
<pos> (see page 1128)
:TIMebase:POSition?
(see page 1128)
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
:TIMebase:RANGe
<range_value> (see
page 1129)
:TIMebase:RANGe? (see
page 1129)
<range_value> ::= time for 10 div
in seconds in NR3 format
:TIMebase:REFClock
{{0 | OFF} | {1 |
ON}} (see page 1130)
:TIMebase:REFClock?
(see page 1130)
{0 | 1}
:TIMebase:REFerence
{LEFT | CENTer |
RIGHt | CUSTom} (see
page 1131)
:TIMebase:REFerence?
(see page 1131)
<return_value> ::= {LEFT | CENTer
| RIGHt | CUSTom}
:TIMebase:REFerence:L
OCation <loc> (see
page 1132)
:TIMebase:REFerence:L
OCation? (see
page 1132)
<loc> ::= 0.0 to 1.0 in NR3
format
:TIMebase:SCALe
<scale_value> (see
page 1133)
:TIMebase:SCALe? (see
page 1133)
<scale_value> ::= time/div in
seconds in NR3 format
