Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 175
:TIMebase:VERNier {{0
| OFF} | {1 | ON}}
(see page 1134)
:TIMebase:VERNier?
(see page 1134)
{0 | 1}
:TIMebase:WINDow:POSi
tion <pos> (see
page 1135)
:TIMebase:WINDow:POSi
tion? (see page 1135)
<pos> ::= time from the trigger
event to the zoomed view
reference point in NR3 format
:TIMebase:WINDow:RANG
e <range_value> (see
page 1136)
:TIMebase:WINDow:RANG
e? (see page 1136)
<range value> ::= range value in
seconds in NR3 format for the
zoomed window
:TIMebase:WINDow:SCAL
e <scale_value> (see
page 1137)
:TIMebase:WINDow:SCAL
e? (see page 1137)
<scale_value> ::= scale value in
seconds in NR3 format for the
zoomed window
Table 57 :TIMebase Commands Summary (continued)
Command Query Options and Query Returns
Table 58 General :TRIGger Commands Summary
Command Query Options and Query Returns
:TRIGger:FORCe (see
page 1142)
n/a n/a
:TRIGger:HFReject {{0
| OFF} | {1 | ON}}
(see page 1143)
:TRIGger:HFReject?
(see page 1143)
{0 | 1}
:TRIGger:HOLDoff
<holdoff_time> (see
page 1144)
:TRIGger:HOLDoff?
(see page 1144)
<holdoff_time> ::= 60 ns to 10 s
in NR3 format
:TRIGger:LEVel:ASETup
(see page 1145)
n/a n/a
:TRIGger:LEVel:HIGH
<level>, <source>
(see page 1146)
:TRIGger:LEVel:HIGH?
<source> (see
page 1146)
<level> ::= .75 x full-scale
voltage from center screen in NR3
format.
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:LEVel:LOW
<level>, <source>
(see page 1147)
:TRIGger:LEVel:LOW?
<source> (see
page 1147)
<level> ::= .75 x full-scale
voltage from center screen in NR3
format.
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
