Krone Comprima CF 155 XC - 8.10.5 Drive lifter manually upward; downward (Comprima CF155 XC;CV210 XC); 8.10.6 Opening;closing the bale chamber

KRONE ISOBUS Terminal
151
Pos: 48.117 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- Press-Wickelvorric htung/Hauptmenüs/ Hauptmenü 3 Handbedienung/ Heber manuell nach oben/ unten fahren @ 233\mod _1393915769543_78.doc x @ 1856905 @ 33 @ 1
8.10.5 Drive lifter manually upward/ downward (Comprima CF155XC/CV210XC)
4
3
1
2
0
0
R
CC000283_1
3-1
Fig. 112
• Use the softkey
to move the lifter rearward as long as the softkey is activated or the
top end position has been reached.
• Use the softkey
to move the lifter forward as long as the softkey is activated or
until the bottom end position is reached.
Possible status messages window 3 (bale chamber); see chapter “Status messages”.
Pos: 48.118 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- Press-Wickelvorric htung/Hauptmenüs/ Hauptmenü 3 Handbedienung/ Ballenkammer ö ffnen/schließen @ 214\m od_1390806784648_78.d ocx @ 1759633 @ 33 @ 1
8.10.6 Opening/closing the bale chamber
4
3
1
2
0
0
R
CC000282_1
3-1
Fig. 113
• Softkey
opens the bale chamber as long as the softkey is pressed or until the
opened end position is reached.
• Softkey
closes the bale chamber as long as the softkey is pressed or until the
closed end position is reached.
Possible status messages window 4 (bale chamber) see Section "Status messages".
