Maintenance
284
Pos: 59.34 /BA/W artung/Sensoren/Sensor Position Messerboden CF/ CV @ 75\mod_1309353586508_7 8.docx @ 662585 @ 44 @ 1
13.4.1.3 Sensor Position Cutter base (B8)
COM00022
1
2
3
Fig. 223
CAUTION!
Damages to the machine.
• When setting the sensor (1) for the position of the cutter base, the cutter drawer (2) must
rest closely against the cutting system housing (3). Therefore, existent soiling in this area
needs to be removed before the setting.
