13.3 Setting of the Scraper Rail to the Upper Spiral Roller
Pos: 59.14 /BA/Bedienun g /Rundballenpresse/ Heckklappe öffnen @ 59\mod_1297675801136 _78.docx @ 559288 @ @ 1
• Open tailgate.
Pos: 59.15 /BA/Sic herheit/7. Gefahrenhin weise alt/Rundballe npresse/WARNUNG Absperrhahn Hydraulikzyl geschlo ssen @ 308\mod_14169950342 89_78.docx @ 2391935 @ @ 1
WARNING! – Settings on the machine!
Danger to life or serious injuries.
• The shut-off valve on the left hydraulic cylinder must be closed.
Pos: 59.16 /BA/Er stinbetriebnahme/Rundba llenpresse/Heckk lappe sperren Compri ma F/V + CF/CV @ 81\mod_13159065 73632_78.docx @ 709150 @ @ 1
a
1
1
b
b
a
1
1
CPK00230_3
Fig. 216
• Swivel shut-off valve (1) in the return of the left lifting cylinder from position (a) to position
(b), the tailgate is locked hydraulically.
