11.18.2 Components Bale Wrapper
Pos: 55.168.7 /Abkürzu ngen /Abkürzungen spr achneutral/Rundba llenpressen/Compr ima CF 155 XC_fett @ 66\mod_130 2006789716_78. docx @ 593531 @ @ 1
Comprima CF 155 XC
Pos: 55.168.8 /BA/Bedi enung /Rundballenpr esse/Ballenwickl er/Bild Bauteile Bal lenwickler CF155 @ 75\mod_1 309263830822_78.doc x @ 661034 @ @ 1
CPN00025_2
1
2
3
4
7
6
5
8
Fig. 194
Pos: 55.168.9 /BA/Bedi enung /Rundballenpr esse/Ballenwickl er/Legende Bauteil e CF155 @ 75\mod_130926385014 8_78.docx @ 661062 @ @ 1
1 Tailgate
2 Lifter
3 Swivel table
4 Double wrapping arm
5 Stretch sheet roll
6 Setting down bales
7 Sheet roll mounting shaft
8 Holding-down device and cutting device
