Maintenance
299
Pos: 59.94 /BA/W artung/Rundballenpres se/Stückzahl Schr aubverbindung an den Rollbö den CF/CV @ 71\mod_1306155972 678_78.docx @ 643830 @ @ 1
For changing all screws on the floor conveyor of the machine, the following unit numbers are
needed:
Designation Material no.
Comprima
CF155XC
Comprima CV150XC
Floor
conveyor
at front
Floor
conveyor
at rear
Total
Coach bolt
M10x35
90 001 687 0 220 100 164 264
Detent edged
washer SKM 10
00 909 909 1 220 100 164 264
Lock nut M10 A3G 00 908 758 0 220 100 164 264
Pos: 59.95 /Abkürzun gen /Abkürzungen sprac hneutral/Rundbal lenpressen/Compri ma CV 210 XC @ 140\mod_13553023820 14_0.docx @ 1248291 @ @ 1
Comprima CV 210 XC
Pos: 59.96 /BA/W artung/Rundballenpres se/Stückzahl Schr aubverbindung an den Rollbö den V/CV 210 @ 295\mod_1412233 307139_78.doc x @ 2320822 @ @ 1
Designation Material number
Front floor
conveyor
Rear floor
conveyor
Total
Coach bolt M10x35 90 001 687 0 86 108 194
Coach bolt M10x60 90 001 953 0 30 108 138
Detent edged
washer SKM 10
00 909 909 1 116 216 332
Locknut M10 90001 230 0 116 216 332
Countersunk screw
Torx M10x25
90 000 521 0 116 216 332
Pos: 59.97 /BA/W artung/Rundballenpres se/Novo Grip @ 216\mod_1390828 279663_78.docx @ 176268 2 @ 22 @ 1
13.12 Novo Grip belt on the floor conveyor
The Novo Grip belts consist of a composite material (rubber and tissue). Under load, franges
come into being on the cutting edges. They must be removed regularly.
Check the Novo Grip belts at least once a week on the formation of fringes and cut off the
fringes, if necessary.
