5.4.2 Mounting the PTO shaft on the machine side
Pos: 42.40 /BA/Sic herheit/Gelenkwelle/ Gefahr - Sich dr ehende Gelenkwelle_2 @ 0\mod_11997 81692950_78.doc x @ 34523 @ @ 1
Danger! - Rotating PTO shaft
Effect: Danger to life or serious injuries
• Install or detach the PTO shaft only with the engine switched off and the ignition key
removed.
• Secure the tractor against rolling.
• Make sure that the PTO shaft is coupled properly (the lock of the PTO shaft must have
snapped in).
• Make sure that the protective devices are attached properly.
• Never use a PTO shaft, the protective devices of which have not been attached.
• Replace damaged protective devices immediately
• Attach the safety chain of the PTO shaft so that the guard tube does not rotate
simultaneously with the PTO shaft.
Pos: 42.41 /BA/Sic herheit/Gelenkwelle/ Gefahr - Antriebsdreh zahl 540 beachten @ 3\mod_1 205316518245_78.doc x @ 73595 @ @ 1
Danger! - Observe drive speed
Effect: Danger to life or serious injuries
• This machine is driven at a maximum PTO speed of 540 rpm.
Pos: 42.42 /BA/Inbetr iebnahme/Wender /Anbau Gelenkwelle/ Hinweis Montage Gelenkwe lle @ 20\mod_1239024536740 _78.docx @ 227900 @ @ 1
Note
When mounting the universal shaft, make sure that the overload protection system will be
installed on the side of the machine.
