Krone Comprima CF 155 XC - 8.14 Main Menu 5 Information; 8.15 Main Menu 6 Technician

KRONE ISOBUS Terminal
179
Pos: 48.194 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- Press-Wickelvorric htung/Hauptmenüs/ Hauptmenü 5 Info/Hauptmenü 5 I nfo @ 144\mod_1359380594 763_78.docx @ 1290725 @ 22 @ 1
8.14 Main Menu 5 Information
CC000298
5
CC000297_1
5-1
SW: 20083040
Fig. 134
Calling the Main Menu
• By pressing function key from the basic screen you get into the menu level of the
machine
• Select main menu 5 (
) by pressing function key or , the symbol is shown in
reverse colours
• Press
function key
The display shows menu 5 “Information".
Complete software version of the machine
SW = Complete software version of the machine
= Software of the job computer
ISO = ISO software version of the job computer
Pos: 48.195 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- BiG Pack/Hauptmenüs/ESC dr ücken um Menü Info 5 zu schließe n bzw. zum Grundbild zuge langen @ 44\mod_12759089 86375_78.docx @ 393962 @ @ 1
• Pressing the function key closes the called up menu
The display shows menu level 5 "Info".
• Pressing the function key
and holding it down brings up the basic screen
Pos: 48.196 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI- BiG Pack/Hauptmenüs/Hau ptmenü 6 Monteur/Haupt menü 6 Monteur @ 135\mod_1351 678746690_78.docx @ 1203319 @ 22 @ 1
8.15 Main Menu 6 Technician
Calling the Main Menu
CC000051
6
CC000052_1
15-6
054536
0000
Fig. 135
• By pressing function key
in the basic screen you get into the menu level
• Select main menu 6
by pressing function key or . The symbol is highlighted
in grey.
• Press function key
Main menu 6 "Technician" is password-protected.
