Operation
255
Pos: 55.168.19 /Übersc hriften/Übersc hriften 3/F-J/Funkti on Ballenwickler @ 74\ mod_1309252590972_78. docx @ 660673 @ 3 @ 1
11.18.3 Function Bale Wrapper
Pos: 55.168.20 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Funktion Ballen wickler allgemein @ 75\ mod_1309263885755_78. docx @ 661146 @ @ 1
When the bale chamber is full, an audio signal will be heard and the drive must stop the
machine. The two net guide rollers deliver the net into the bale chamber and the bale is tied.
If the net tying process is completed, the tailgate of the machine opens and the bale falls onto
the lifter (Comprima CF155XC) or wrapping table (Comprima CV150XC).
Pos: 55.168.21 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Funktion Ballen wickler CF155 @ 75\mod_130 9263901238_78.doc x @ 661174 @ @ 1
Just Comprima CF155 XC
The lifter lifts the bale onto the swivel table which is fitted behind. The lifter is lowered and the
tailgate closes again.
Pos: 55.168.22 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Funktion Ballen wickler CV150 @ 75\mod_130 9263902550_78.doc x @ 661202 @ @ 1
Just Comprima CV150 XC
The wrapping table transports the bale onto the swivel table which is fitted behind. The
wrapping table does not move and the tailgate closes again.
Pos: 55.168.23 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Funktion Ballen wickler Ballen ableg en (XC) @ 75\mod_1309263917 815_78.docx @ 661230 @ @ 1
The wrapping process is started in the wrapping device while a new bale is compacted in the
bale chamber.
The bale rolls onto the driven swivel table while the wrapping arm circles at the same time
around the bale and wraps it witch stretch sheet. After a pre-set number of wraps, this working
process stops automatically.
As soon as the driver stops because the next bale has been compacted completely and
imbedded the net, the swivel table inclines to the rear. The bale is set down on a rubber cover
behind the machine.
Pos: 55.168.24 /Abkürz ungen /Abkürzungen spr achneutral/Rundb allenpressen/Co mprima CV 210 XC @ 140\mod_135530 2382014_0.docx @ 1248291 @ @ 1
Comprima CV 210 XC
Pos: 55.168.25 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Funktion Ballen wickler Ballen ableg en HD @ 102\mod_1331029256066 _78.docx @ 901779 @ @ 1
When the bale chamber is full, an audio signal will be heard and the driver must stop the
machine. The two net guide rollers transfer the net into the bale chamber and the bale is tied
there.
The tailgate opens if the net tying process is completed. The bale is transferred from the bale
chamber to the wrapping table via gravity. If necessary, the lifter activated by a sensor supports
the bale transfer on slopes.
Note
The bales should not be placed down while the machine is moving as this could lead to
damages of the sheet.
Note
Wrap the bale all-round with at least six layers of sheet. The overlapping of each two layers of
sheet must be 50%.
