4.10 Technical data
All information, illustrations and technical data in these operating instructions correspond to the
latest state at the time of publication. We reserve the right to make design changes at any time
and without notification of reasons.
Pos: 40.6 /BA/Einlei tung/Technische Date n/Rundballenpress e/Technische Daten Com prima CF 155 XC @ 65\mod_13012993 36103_78.docx @ 588104 @ @ 1
Comprima CF155 XC
Axle Tandem axle (axle base 1100)
Permissible weights
see information listed on the identification
plate
Pick-up width 2150 mm
Width approx. 2950 mm
Track width 2455 mm
Tyres 500/50-17 10 PR
500/55-20 12 PR
Length approx. 6578 mm
Height approx. 3410 mm
Bale dimensions Diameter approx. 1250 - 1500 mm
Width approx. 1200 mm
Power requirement approx. 51 kW (70 PS)
Drive speed (PTO shaft) 540 r.p.m.
max. permissible operating pressure of
hydraulic system
200 bar
max. oil temperature 80°C
Delivery rate hydraulics min. 30 l/min max. 60 l/min
Electr.
connections
Lighting 12 volt – 7-pole connector
Operation 12 volt – 3-pole connector
Net max. Width 1300 mm
Sleeve length 1250 - 1350 mm
Sleeve diameter ø 75 - 80 mm
Roll diameter max. 310 mm (3000 m roll)
Sheet Width 2 x 750 mm (500 mm also possible)
Pre-stretch 50% or 70%
Sleeve diameter ø 75 - 80 mm
Roll diameter max. 260 mm
Overload protection system (universal shaft)
Cam-type clutch 540 rpm
1950 Nm (17 blades)
2300 Nm (26 blades)
Pos: 40.7 /BA/Einlei tung/Technische Date n/Rundballenpress e/Technische Daten Com prima CF 155/CV 150 XC_Hydr aulikanschlüsse @ 226\ mod_1392657293830_78. docx @ 1825261 @ @ 1
Hydraulic Connections
Raising/lowering the pick-up or blade base 1 x single-action control unit
