Operation
257
Pos: 55.168.30 /Übersc hriften/Übersc hriften 3/F-J/Folie ei nlegen @ 75\mod_130926233 7743_78.docx @ 660953 @ 3 @ 1
11.18.5 Inserting Sheet
Pos: 55.168.31 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Folienrollen ei nlegen @ 75\mod_13092 64497329_78.docx @ 661286 @ @ 1
CPN00004_2
1
2
CPN00003_1
4
3
5
Fig. 197
Note
Up to 10 sheet rolls can be stored in both sheet boxes (2) to the right and to the left.
• Open sheet box door (1)
• For swivelling the sheet roll holder (3), loosen the locking (4) and pull the sheet roll holder
forward until the indentation (5) snaps into place in the locking lever
Pos: 55.168.32 /Layout Module /------ ---------Seitenumbruc h---------------- @ 0\mod_1196175311226_0. docx @ 4165 @ @ 1
