Safety
49
Pos: 38.44 /Übersc hriften/Überschri ften 3/P-T/Trittstuf e für Arbeiten am Bindemec hanismus @ 292\mod_1411108 971813_78.doc x @ 2303616 @ 33 @ 1
4.7.11 Step for working on the linkage
Pos: 38.45 /BA/Sic herheit/2. Vorangeste llte Warnhinweise/W ARNUNG - Zugang zur Maschine Comprima @ 295\mod_14119948709 48_78.docx @ 2316787 @ @ 1
WARNING!
Risk of injury when climbing up and down.
People who behave carelessly when climbing up and down may fall off the ladder. People, who
climb onto the machine without using the designated ladders, may slip, fall and seriously injure
themselves. Dirt as well as operating fluids and lubricants may cause you to lose your footing.
• Use the designated ladders only.
• Always keep the steps and platforms clean and in a proper condition to prevent people from
losing their footing.
• Never climb up and down while the machine is moving.
• Face the machine when climbing up and down.
• When climbing up and down, never use the control elements as handles. Inadvertent
activation of the control elements may cause functions to be unintentionally actuated which
could be hazardous.
• When climbing down, never jump off the machine.
Pos: 38.46 /BA/Sic herheit/Rundballenpr esse/Bild Tritts tufe Netzbindung_Compr ima @ 292\mod_14111142830 56_78.docx @ 2303815 @ @ 1
1
Fig. 18
Pos: 38.47 /BA/Sic herheit/Rundballenpr esse/Trittstufe Bi ndemechanismus_Co mprima @ 292\mod_141110942 3771_78.docx @ 2303683 @ @ 1
Attached to the right-hand side of the machine at the front above the roller crop guide is a step
(1) that allows easier access to the linkage and the supply of binding material.
