Operation
253
Pos: 55.168.11 /Abkürz ungen /Abkürzungen spr achneutral/Rundb allenpressen/Co mprima CV 150 XC (fett) @ 83\mod_ 1317819279881_78.doc x @ 731653 @ @ 1
Comprima CV 150 XC
Pos: 55.168.12 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Bild Bauteile Bal lenwickler CV150 @ 75\mod_1 309263858601_78. docx @ 661090 @ @ 1
CPN00026_2
1
3
4
7
6
5
8
2
Fig. 195
Pos: 55.168.13 /BA/Bedi enung /Rundballenpr esse/Ballenwic kler/Legende Bautei le CV 150 @ 75\mod_130926387381 8_78.docx @ 661118 @ @ 1
1 Tailgate
2 Wrapping table
3 Swivel table
4 Double wrapping arm
5 Stretch sheet roll
6 Setting down bales
7 Sheet roll mounting shaft
8 Holding-down device and cutting device
