Maintenance
280
Pos. Sensor designation
Distance
Transmitter/sensor
Operating
terminal CCI
Sensor type
Starting
torque
1 Net length (B1) 2 mm X Namur 10 Nm
2 Net running (B2) 2 mm X Namur 10 Nm
3 Position of net motor
(B3)
X Rotation pulse
encoder
4 Bale chamber closed
right (B12)
2 mm X Namur 10 Nm
5a Bale firmness right
(B10) (CF155XC)
X Rotation pulse
encoder
5b Bale diameter right
(B10) (CV150XC)
X Rotation pulse
encoder
6 Bale on swivel table
right (B17)
X Namur 10 Nm
7 Holding arm right
(B23)
4 mm X Namur 10 Nm
8 Sheet tear control
(B24)
