Maintenance
314
Pos: 59.155 /BA/W artung/Rundballenpres se/Allgemeines Eige nhydraulik CF/CV @ 76\mod_1 309950686055_78.d ocx @ 665511 @ @ 1
The on-board hydraulic pump is driven via a gear directly by the PTO shaft. The hydraulic tank
is located on the left rear machine side. The hydraulic filter of the on-board hydraulic system is
located at the front left on the machine. The control valves are located at the sheet
compartment on the left side of the machine.
Pos: 59.156 /BA/W artung/Rundballenpres se/Bild Bauteile Eige nhydraulik CF/CV @ 76\mod_13 09949643837_78.doc x @ 665453 @ @ 1
Y 15
Y 16
Y 11
Y 13
Y 07
Y
1
7
Y
1
0
Y
1
2
Y
0
8
Y
0
6
Y
0
4
Y 05
Y 14
CPN00020_2
Fig. 248
Y04 Function I (S10) Y012 Transfer forward (S5)
Y05 Valve block Y013 Transfer back (S4)
Y06 Control valve wrapping arm (S1) Y014 Sheet tear (S12)
Y07 Close bale chamber (S2) Y015 Release holding arms (S13)
Y08 Open bale chamber (S3) Y016 Open holding arms (S8)
Y10 Swivel table forward (S7) Y017 Close holding arms (S9)
Y011 Swivel table back (S6)
