REV 0, June 2005 Page 155
Operation Manual SUPREMA
5. Installation
Type of Module Power (VA)/Module
MCP module 5
MDO module 5
MDA module 1
MGO module 1
MAI module 1
MAO module 5
MRO-8 1.5
MRO-8-TS 1.5
MRO-16-TS 3
* Value applies to a bridge current of Ibr = 300 mA
** Only detector and source greater than 6 W. Both (detector and source) should be supplied
by external voltage source.
*** With regard to fire and smoke detection, the SUPREMA has not been evaluated to any
Canadian standard by a third party agency.
After adding the power consumption for the sensors, the following power values can be given
for the individual module cards:
Attention: The supply voltage may be turned on only after all required
installation steps have been completed and the installation has been verified
during the startup procedure (see section Startup).
Table 5-36: Power Requirements of the System
Modules
Type of Sensor Sensor Power Power per Ohm of Cable Resistance
D-7600 1,5 W 0.1 W*
D-7602 1,5 W 0.1 W*
D-7711 1,5 W 0.1 W*
D-715 1.5 W 0.1 W*
D-7152 1.5 W 0.1 W*
D-7100 1.5 W 0.1 W*
Series 47 K 1.5 W 0.1 W*
D-7010 2.5 W 0.1 W*
D-8101/D-8113 1.5 W 0.1 W
DF-7100 2.5 W 0.05 W, max.
DF-7010 4 W 0.05 W, max.
DF-8603 4 W 0.1 W
DF-8201 1.5 W 0.05 W, max.
DF-8250 1.5 W 0.05 W, max.
DF-8501/DF-8502*** 5 W 0.1 W
DF-9500 1 W not applicable
DF-9200 1 W not applicable
IR 3600 230 VAC external
SafeEye 8 W ** 0.1 W
GD10 3.5 W 0.05 W, max.
Ultima X 4 W 0.1 W
Ultima X IR 7 W 0.1 W
Table 5-35: Power
Requirement of the
Sensors and Cables
