Operation Manual SUPREMA
4. Operation of the System
Text Fields
In text fields the operator can enter text and choose between overwrite and insert mode.
When the field is opened, it defaults to overwrite mode. In this mode, Í and Î move
between the character positions and Ï and Ð select the desired characters.
Pressing Ï and Ð simultaneously switches to insert mode. In this mode, pressing Î inserts
a space at the cursor’s position and moves the character under the cursor and all characters
to the right of the cursor one position to the right. Pressing Í lmoves the character under
the cursor and all characters to the right of the cursor one position to the left. Pressing Ï or
Ð leaves insert mode.
Display Fields
Display fields simply display information and are not affected by the cursor keys.
Check Boxes
Check boxes represent options that can be enabled or disabled. Pressing the ↵ key switches
between enabled and disabled.
[x] enabled check box
[ ] disabled check box
Option Fields
An option field represents an individual choice within a set of mutually exclusive choices. Pressing
↵ in a disabled option field enables it and disables the previously enabled field.
List Displays
List displays simply display information. No parameters can be entered The cursor keys can be
used to scroll through list displays. Press ESC to leave the list display.
Overview of Operator Keys
Key Name Function in a menu Function in an input field
Í
Back Move back one field Move back one character position,
move decimal point to the left
Î
Forward Move forward one field Move forward one character position,
move decimal point to the right
Ï
Up Move to field above Previous selection value or higher number valu
e
Ð
Down Move to field below Next selection value or lower number value
ESC Cancel Without changing the menu list Leave field without changing
↵
Execute Open current field to change, Accept changed field contents
execute field function (button) and leave field
Table 4-1: Overview of operator keys
4.2.3.1 Operation menu structure
The operation menu is divided into four submenus:
• Measure
• Setup
• Maintain
• Diagnosis
These submenus can be called up by selecting the corresponding menu item. The „Measure”
submenu is automatically activated at system startup.
