MSA SUPREMA - Software Versions Allowed; Safety-Relevant Parameters

REV 0, June 2005 Page 381
Operation Manual SUPREMA
15. Special conditions
15.2.2 Software Versions Allowed
15.2.3 Safety-relevant Parameters
- Hardware Failure Tolerance: HFT = 1
- Safe-Failure-Fraction: SFF = 94 %
- Probability of failure per hour:
System without CAN-components: PFH
1
= 2,4
*
10
-8
1/h
System with CAN-Bridge: PFH
2
= 3,4
*
10
-8
1/h
System with CAN-Bridge and CAN-LWL: PFH
3
= 4,3
*
10
-8
1/h
Module Software version Software version
Flash resp. EPROM CPLD
MCP 10 2.02.15
MDO 10 2.02.15b
MDA 10 1.02.02 MDA MA01
MAO 10 2.02.01 MAO MA01
MGO 10 2.02.06 MGO MA01
MAI 20 MAI MA01
MAR 10 MAR MA01
