Table 14-1: Modules tested according to DMT 03 ATEX G 003 X
Passive Remote Sensors according to DMT 03 ATEX G 003 X
- D-7010
- D-7100
- D-715 K
- D-7152 K
- D-7711 K
- D-7711 K-PR
- Series 47 K-ST
- Series 47 K-PRP
Module Layout version Meaning
MIB 20 2 Interconnection Board
MCP 10 10 Central Processing Unit
MDO 10 11 Display & Operation
MDA 10 9 Data Acquisition
MGO 10 15 General Output
MAO 10 6 Analog Output Unit
MAI 20 6 Analogue Input Unit
MAR 10 6 Analogue Redundant
MST 10 8 System Terminals
MPI 10 WT 100
MPI 10 WT 10 6 Passive Sensor Input
MCI 20 11 Current Input
MAT 10 4 Analogue Terminal
MAT 10 TS 6 Analogue Terminal
MUT 10 4 Universal Terminal
MRC 10 TS 3 Relay Connection
MRO 10-8 7 Relay Output (8 Relays)
MRO 10 8-TS 3 Relay Output (8 Relays)
MRO 10 16 TS 3 Relay Output (16 Relays)
MRD 10 2 Relay Dummy
SUPREMA Rack-Type 20/E 20
(With or without internal 150 W
power supply)
SUPREMA CAN BRIDGE CBM 10034641
MGT 40 TS 10026772
