MSA SUPREMA - Listing of the States of Versions Which Are Valid for SIL 3; Modules Allowed

REV 0, June 2005Page 380
Operation Manual SUPREMA
15. Special conditions
15.2 Listing of the states of versions which are valid for SIL 3
15.2.1 Modules allowed
Only the following modules may be used for SIL 3 applications:
For not safety-related applications (e.g. analogue output, data communication to a PLS) the following
components can also be used:
Module Layout version "G" state Meaning
MAO 10 6 E Analogue Output Uni
t
MHD 10 High Driver
MGT 40 TS General Terminal
SUPREMA PKV 30-COS/AUER
* With regard to fire and smoke detection, the SUPREMA has not been evaluated to any Canadian standard by
a third party agency.
Module Layout version "G" state Meaning
MIB 20 2 A Interconnection Board
MCP 10 10 A Central Processing Unit
MDO 10 11 A Display & Operation
MDA 10 9 A Data Acquisition
MGO 10 12 A General Output
MAI 20 6 A Analogue Input Unit
MAR 10 6 A Analogue Redundant
MST 10 8 A System Terminals
MSI 10 4 B Switch Input
MFI 10* 5 D Fire Input
MCI 20 MCI 20 BFE 11 E Current Input
MAT 10 4 B Analogue Terminal
MAT 10 TS 6 C Analogue Terminal
MPI 10 WT 100 J
MPI 10 WT 10 6 H Passive Sensor Input
MPI 10 HL8101 H
MPI 10 HL8113 H
MUT 10 4 A Universal Terminal
MRC 10 TS 3 B Relay Connection
MRO 10-8 7 C Relay Output (8 Relays)
MRO 10 8-TS 3 B Relay Output (8 Relays)
MRO 10 16 TS 3 C Relay Output (16 Relays
)
MAT TS 320 FLAMMABLE 1 A Analogue Terminal
MAT TS 320 TOXIC 1 A Analogue Terminal
MRD 10 2 A Relay Dummy
SUPREMA Rack-Type 20/E 20
(With or without internal 150 W C
power supply)
SUPREMA CAN BRIDGE CBM
SUPREMA CAN-LWL Konverter - Fibre Optics Converter
