REV 0, June 2005 Page 205
Operation Manual SUPREMA
7. Maintenance and Service
7.9 Display of Digital Messages
ID Rack Assignment in decimal and hexadecimal figures
These ID are reserved for gateways (MOD-Bus, Profibus etc.)
Table 7-5: Display of the digital messages
The highest priority messages (“1” means highest priority) are displayed first. Messages with a
lower priority are displayed in addition if these use other indicating ranges for message display.
Slot No. 16 of a rack is reserved for the MDO 10 only. Only one MDO 10 can be contacted in
one system.
Rack 1
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID hex.
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
10
Rack 2
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
ID hex.
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
Rack 3
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
ID hex.
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
Rack 4
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
ID hex.
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
40
Rack 5
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
ID hex.
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
Rack 6
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
ID hex.
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
Rack 7
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ID dec.
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
ID hex.
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
Rack 8
Slot
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
ID dec.
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
ID hex.
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
Message Priority Display (List) LEDs/Relays
Alarm 1 9 Measure point status 1st Alarm Signal AL 1 at
Alarm 2 8 Measure point status 2nd Alarm Signal AL 2 at
Alarm 3 7 Measure point status 3rd Alarm Signal AL 3 at
Alarm 4 6 Measure point status 4th Alarm Signal AL 4 at
System error 1 System Fail at
Signal error 3 Meas. point status Signal failure Signal Fail at
Module error 1 Module failure a
t
CAN-Bus failure 1 CAN failure at
Free 1 Measure point status free
Measuring 10 Measure point status measuring
Inhibit 2 Measure point status inhibited Inhibit at
Calibration 6 Measure point status calibration Inhibit at
Sensor warm-up 4 Measure point status suppressed Inhibit at
Measuring range overflow 5 Measure point status overflow Signal Fail at
New value 1 Signal blinking
Table 7-4: ID Rack Assignment in decimal and hexadecimal figures
