REV 0, June 2005Page 204
Operation Manual SUPREMA
7. Maintenance and Service
ERROR LED: see 7.6.1 LED 4; FAIL LED: see 4.2.2
F. Failure Appears in case of Disappears in Error Fail Info 1 Info 2 Module Remarks/Remedial
No. Message case of LED LED (BYTE) (DWORD) action
Text
10 Error in Flash error detected Whole flash X X Sector Block = low MCP Hardware defect.
configuration (Self-test of the con- tested error- Chksum = hi MDO Exchange module
memory at figuration an para- free (after Perhaps sequence erro
r
meter memory) approx. 24 h) of No. 9
11 Data lost at Error at serial Restart X X No. of the Indication MDO Data lost at PC interface
serial communication interface char = l0, or printer interface:
communi- status = hi Check cables, perhaps
cation at hardware defect: ex-
change MDO module
12 Node Module does not All nodes X X ID Module No of MAI, MCP CAN-Bus failure, modul
e
guarding respond to node- respond again failure; CAN bus or 0; MDO defect or missing: Chec
k
error guarding, or does for MGO for MGO: time MGO bus and modules.
detected by not send any "0" MGO is sending this
heartbeat message if no output
data have been received
for a certain time
13 Programm Application Restart X X Application Various MCP Normally software
error at programm error fault no. MDO problems (not plausible
internal software status
)
14 Data error Application Restart X X Data Data set MCP On parameter data
at data error set index + MDO matching records of
subindex Module-ID different contents with
indentical revision code
have been detected: Se
t
parameters by manual
selection. Often se-
quence error of No.
9 or 10.
15 System The system configu- Restart X X ID con- Type of all Modules on wrong plug
configuration ration detected does cerned profle + positon? Several racks
error at not correspond to the Module additional of the same ID (switch)
configuration stored or info in the system?
is not consistent
16 Data SPI communication SPI commu- X X MDA: Mux MDA:error MDA MAI or MDA defect. Can
acquisition error between MDA nication resp. OK=1 type; MDA: MGO also be caused by defe
ct
error at and MAI or at digital outputs all right else 0 Input No. rack. Always appears
outputs (MGO) again MGO: MAI/channel if a MDA but not a MAI, is
error type MGO: diagno- being plugged in a rack
.
sis code MGO: Outputs short-
circuited or open.
