6. Startup
6. Startup
Attention: High voltages can be present in the MSP module and at the relay
terminals of the relay modules. Suitable safety measures must be taken when
starting up the system.
Startup procedures may be performed only by authorized and qualified
personnel.
Before startup, it must be ensured that all installation steps have been executed
properly and that the cable connections and configurations of the individual
modules as well as of the entire system are correct.
Startup is to be performed by executing the following steps:
• Make sure that the voltage supply is turned off.
• Check to make sure that the sensor, relay, switching output, and analog output
connections of the system are disconnected.
• Ensure that all the required modules have been properly mounted in the system and are
connected to each other.
• In systems with several racks, make sure the CAN bus connection is correct (cabling,
baud rate, CAN node no., terminating resistor).
• Turn on the supply voltage.
• System Configuration (Configuration Tool)
• Connect and configure the sensors.
• Connect and configure the relay or switching outputs.
• Give the sensors a preliminary calibration.
• Subject the overall system to a function test with gas.
6.1 Turn On the Supply Voltage
Turn on the supply voltage to the system under consideration of all relevant safety measures.
After the power is turned on, the message “AUER SUPREMA MDO Module” appears on the
display of the front panel (MDO module) along with the current software and hardware revision
nos. At the same time, all LEDs light up. After the module has run through a self-test, it starts
the system with the message “system start in progress”. After the system starts successfully,
the number of inputs corresponding to the plugged-in MAI modules is displayed in the “Measure/
List” menu.
Note: If this process is not completed in 15 minutes, the installation should be
checked again. If necessary, an MSA service technician should be called in to
correct the problem.
