4. Operation of the System
The following paragraphs describe the functions of the individual menu items. The first items
discussed are those that are identical in all three submenus.
Measure Point No.
Field type: Selection field
The field contains a list of all configured inputs. It also contains inputs which no longer physically
exist, but whose parameters are still stored in the system. Those inputs are only removed from
selection when the user deletes them in the Measure Point menu.
After an input number is selected, the rest of the menu is filled, if that input has already been
configured. If an input number is selected that has not been configured before, the settings
from the last displayed input remain and are used as the preliminary settings for the new input.
This makes it easy to copy the settings from one input to another. If an input is displayed that
has not yet been configured, default values are used as the preliminary settings for the input of
certain fields. This selection field can be accessed without a key switch or password if an input
is entered for which input parameters have already been set. If a number is entered that has
not been used before, authorisation by means of password or key switch is required.
All parameter changes using the menu items described below apply to the inputs selected
in that field.
Inhibit
Field type: Check box
If this check box is enabled, the selected inputs cannot trigger alarms.
Information, Sensor Data, Alarms
Field type: list
Pressing the appropriate button will display the corresponding submenu.
“Information” submenu
The “Information” submenu contains general data on the selected input.
MeasurePoints RelayOutput System Menu A
Measure Point No.: 1 Inhibit [ ]
[Information] [Sensor Data] [Alarms]
Tag: Q-123
Marking: SP-05
Sensor Ser. Nr.: 115
Install Area: Feld 14
[OK] [Cancel] [Clear]
Figure 4-7: “Information” submenu
Tag
Field type: text
Enter a customer-specific designation for the selected input
Marking
Field type: text
Enter a customer-specific description for the selected input
