MSA SUPREMA - Table 5-8: MAO Module, Configuration of Turn-On Behaviour and Failure Behaviour

REV 0, June 2005Page 98
Operation Manual SUPREMA
5. Installation
Table 5-8: MAO Module, Configuration of turn-on behaviour and failure behaviour
Turn-on Behaviour and Failure Behaviour of the MAO Module
During turn-on, at the analogue outputs a 0 mA signal is issued.
CAN FREE Baud Rack
ABAB421421
Turn-on Behaviour at CAN-Bus 1 2 3 4 5 6 7 8 9 10
behaviour failure
In the case of alternative assembly 10 9 8 7 6 5 4 3 2 1
All analogue outputs All analogue outputs keep there
ON ON
are 0 mA. last state.
All analogue outputs All analogue outputs keep there
OFF
ON
are 2 mA. last state.
All analogue outputs After ca. 2 min all analogue
ON OFF
are 0 mA. outputs are 0 mA.
All analogue outputs After ca. 2 min all analogue
OFF
OFF
are 2 mA. outputs are 2 mA.
Explanation of the symbols:
= Any switch
