REV 0, June 2005Page 136
Operation Manual SUPREMA
5. Installation
MGT-40-TS Module/Sensor Connections
Table 5-21: MGT-40-TS Module, Terminal Assignments for Connection of the Sensors
MAI Module MAI Module MAI Module MAI Module MAI Module
with MPI with MPI with with with MPI
Module (WT) Module (WT) MCI Module MCI Module Module (HL
Measurem. MGT-40-TS Module Catalytic/passive Catalytic/passive active/ active/ Semiconduc
Point No. Terminal No. 5-wire 3-wire 2-wire 3-wire tor/4-wire
1 2 K‘ (white) signal signal +M (white)
1 K (brown) K (brown) +24 V +24 V +H (green)
4 0 (green) 0 (green) -M (brown)
3 D (yellow) D (yellow) GND -H (yellow)
6 D‘ (grey)
2 5 K‘ (white) signal signal +M (white)
8 K (brown) K (brown) +24 V +24 V +H (green)
7 0 (green) 0 (green) -M (brown)
10 D (yellow) D (yellow) GND -H (yellow)
9 D‘ (grey)
3 12 K‘ (white) signal signal +M (white)
11 K (brown) K (brown) +24 V +24 V +H (green)
14 0 (green) 0 (green) -M (brown)
13 D (yellow) D (yellow) GND -H (yellow)
16 D‘ (grey)
4 15 K‘ (white) signal signal +M (white)
18 K (brown) K (brown) +24 V +24 V +H (green)
17 0 (green) 0 (green) -M (brown)
20 D (yellow) D (yellow) GND -H (yellow)
19 D‘ (grey)
5 22 K‘ (white) signal signal +M (white)
21 K (brown) K (brown) +24 V +24 V +H (green)
24 0 (green) 0 (green) -M (brown)
23 D (yellow) D (yellow) GND -H (yellow)
26 D‘ (grey)
6 25 K‘ (white) signal signal +M (white)
28 K (brown) K (brown) +24 V +24 V +H (green)
27 0 (green) 0 (green) -M (brown)
30 D (yellow) D (yellow) GND -H (yellow)
29 D‘ (grey)
7 32 K‘ (white) signal signal +M (white)
31 K (brown) K (brown) +24 V +24 V +H (green)
34 0 (green) 0 (green) -M (brown)
33 D (yellow) D (yellow) GND -H (yellow)
36 D‘ (grey)
8 35 K‘ (white) signal signal +M (white)
38 K (brown) K (brown) +24 V +24 V +H (green)
37 0 (green) 0 (green) -M (brown)
40 D (yellow) D (yellow) GND -H (yellow)
39 D‘ (grey)
