REV 0, June 2005 Page 133
Operation Manual SUPREMA
5. Installation
Press E and >Enter<, to write the parameters into the memory, and then check them by
pressing R and >Enter<.
e
>r
B0:6
I0:0 I1:0
I0:80 I1:80
I0:100 I1:100
I0:614 I1:614
I0:714 I1:714
I0:21e I1:21e
I0:61e I1:61e
I0:71e I1:71e
B1:9
M1:0:0xxxxxxxxxxxxxxxxxxxxxxxxxxxxx
The parameters have now been successfully set.
Note: The parameter setting of a CAN bridge for the CAN Bus B is carried out the
same way as the parameter setting for the CAN Bus A.
Technical Data:
Table 5-19: Technical Data CAN-Bridge CBM
Supply voltage Nominal voltage 24 VDC ±10 %
Current consumption (at 20 °C): typ. 85 mA
Plug connector
X 100
(DSUB9, plug) - serial interface
X 101
(6-pin screw connector UEGM) -
24 V supply voltage
X 400-SIO331
(Combicon design, 5-pin
MSTB2.5/5-5.08) - CAN or DeviceNet Net 0
X 400-SIO-CAN2
(Combicon design, 5-pin
MSTB2.5/5-5.08) - CAN or DeviceNet Net 1
Temperatur range 5 ... 50 °C environmental temperature
Humidity 90 % max., noncondensing
Dimensions Width: 40 mm, Height: 85 mm, Depth: 83 mm
of the cabinet (including mounting rail and protuding connector
(W x H x D) DSUB9, without CANDeviceNet plug)
Weight approx. 200 g
