REV 0, June 2005 Page 227
Operation Manual SUPREMA
10. Redundant Systems
10.4.2 Configuration in the Case of New Installation
Generating and Transferring a Configuration File
Connect PC/LAPTOP
• Start the Configurator
• Generate the configuration listing according to the hardware equipment
• Copy the file CONFIG.MDB >> NAME.MDB
• Edit the NAME.MDB data base
• Transfer the configuration listing (NAME.MDB) to the system.
After the program message “Transmission successful”, the configuration listing has been
stored, and the configuration is finished. After this, the system has to be started up once
more by switching off and on.
Note: Generating a configuration file is described in detail in section 10.4.3
Configuration Tool.
Automatic Generation of the Configuration File
• Make a new startup (System OFF/ON)
During warm-up period, the following message appears on the display of the front panel
(MDO Module):
AUER-SUPREMA-MDO-XX
Rev. xxxxxxx HW xxx
During this message, the RESET button has to be pressed for approx. 1 sec. After segment
test of the display, the following message appears:
System configuration
There are several possible system configu-
rations available, please select the
configuration to be used
Module ID Configuration name
——————————————————
[OK]
When selecting “recognised parameters deleted”, the measuring point parameters are
completely deleted, and a new configuration is generated automatically by reading the system
configuration.
Note: By the automatic reading, existing parameters are deleted.
