MSA SUPREMA - SUPREMA Sensor Data Sheet Contact

REV 0, June 2005Page 366
Operation Manual SUPREMA
12. Sensor Data Sheets
12.59 SUPREMA Sensor Data Sheet Contact
Connection data: Maximum nominal current 8 mA
Maximum nominal voltage 15 V
Power consumption ≤1.0 W (including cable length)
Cable type 2-core, 80 % screened
Maximum loop resistance 50 ohms (cable resistance)
Maximum cable length 2000 m (1.5 mm
2
cross section per wire)
Cross section per wire allowed 0.5 ... 2.5 mm
2
Conditions for use: Mounting depending on the switch type
Ingress protection -
Explosion protection no
Certificate depending on the switch type
Temperature depending on the switch type
Humidity depending on the switch type
Pressure depending on the switch type
Weight depending on the switch type
Dimensions depending on the switch type
Housing material depending on the switch type
