Operation Manual SUPREMA
9. Connection of Peripherals
Technical Data:
Table 9-2: Technical Data Suprema Gateway CAN/Profibus DP
Supply voltage Nominal voltage: 24 V/DC ± 10%
current consumption (at 20 °C): 125 mA max.
(+20 mA on TTY operation of the serial interface)
Plug connector X100-SIO331 (DSUB9, plug) - serial interface
X100-CBMPB (DSUB9, socket) - profibus-DP-interface
X101 (6-pin screw connector UEGM) - 24 V supply voltage
X400 (Combicon design, 5-pin MSTB2.5/5-5.08) - CAN or DeviceNet
Temperature range 0 ... 50 °C environmental temperature
Humidity max. 90%, noncondensing
Dimensions of the Width: 40 mm, Hight: 85 mm, Depth: 83 mm
cabinet (including mounting rail and protuding connector DSUB9, without
(W x H x D)
CAN/DeviceNet plug)
Weight Approx. 200 g
