REV 0, June 2005Page 158
Operation Manual SUPREMA
5. Installation
Note: External overcurrent shall be included in the building installation, shall be
in close proximity to the equipment and within easy reach of the operator and
shall be marked as the disconnecting device for the equipment.
Attention: Do not supply line power to the MIB module. This will damage the
SUPREMA system.
The line earth ground wire is connected to the PE terminal of the MSP module. If multiple earth
ground conductors are connected to PE, then the line earth ground conductor must be installed
first and all others installed afterwars.
Note: Before turning on the line voltage during the start-up procedure, reinstall
the Plexiglas cover over the connection terminals of the MSP module in order to
prevent any danger that might arise from accidental contact with the line voltage.
5.12 Labelling Concept
Labelling fields are provided on the various modules for the numbering of the plug-in cards, the
connector plugs, and connected inputs and outputs. The customer is free to mark them in any
way deemed fit except the MPI and MCI modules that are an exception due to the lack of
space. In the following, the labelling fields and a possible plan for marking them is presented.
This plan is merely a suggestion and the customer is free to label the fields in correspondence
with his own concept of the system.
5.12.1 Plug-In modules
The labelling field for the plug-in cards (MCP, MDA, MAI, MGO and MAO modules) is located
on the front, on the release lever for the card. It is therefore immediately visible as soon as the
front panel of the rack has been swung down. The type of module is printed on the lower half.
The upper half is available for the customer to mark. A possible labelling system is illustrated in
the following.
Figure 5-47: Labelling field, plug-in cards
Rack: No of the rack the module belongs to
Module type: MAI, MGO, MAO, MCP or MDA
Slot: No of the slot the module is plugged in
Rack
Slot
MAI
